Insulated Conductor Bar Systems

Versatile and flexible with multiple products from which to choose, VAHLE’s insulated conductor bar systems provide over 100 years of engineering experience. Designed with safety and reliability in mind, many systems are UL, CSA and SEV approved and IP 23 rated. Available in amperages from 10 to 1250 with a variety of housing and conductor material, VAHLE insulated conductor bars can be used in a wide range of applications.

Product Advantages

Multiple models & conductor types for any application

Fully insulated and touch safe housing for increased safety

Compact sizing for reduced space requirements

Low maintenance requirements

System Types

ProfileTypeHousing MaterialConductorMax Amp @ 60%Selection Guide
U10 Insulated Conductor System Configuration U10 PVC
  • Copper
  • Stainless Steel
10-100
  • Indoor
  • Mild Power
  • No Environmental Concerns
U20, U30, U40 Insulated Conductor System Configuration U20 PVC

Hi-Temp PVC
  • Copper
  • Stainless Steel
  • Aluminum
80-210
  • Indoor/Outdoor Systems
  • Medium-High Power
  • High Environmental Concerns
U30 280 - 530
U40 600-1000
U15 Insulated Conductor System Configuration U15 PVC
  • Copper
  • Stainless Steel
10-100
  • Indoor Systems
  • Mild Power
  • No Environmental Concerns
U25, U35 Insulated Conductor System Configuration U25 PVC

Hi-Temp PVC
  • Copper
  • Galvanized Steel
  • Stainless Steel
  • Aluminum
90-450
  • Indoor/Outdoor Systems
  • Medium-High Power
  • Mild/Medium Environmental Concerns
U35 500-1250

 VAHLE insulated conductor bar systems are a proven solution used in a variety of applications including EMS lines, amusement rides, material handling equipment, storage and retrieval systems, overhead cranes and transfer cars. With an extensive range of models available, accessories such as hi-temperature housing, and the ability to custom curve, VAHLE has the right solution for your application.
